Series: Multilayer Varistors

MLV HV Series

Features

  • Bidirectional and symmetrical V/I characteristics Low Capacitance
  • Meet IEC61000-4-2 Standard
  • Large withstanding surge current capability - 400~500A (@8/20μs)
  • Multilayer construction provides higher power dissipation

Related Product

MLV HSP Series
MLV HA Series
MLV NA Series

Electrical Characteristics

Supplier Part Number Part Series Product Type Size Clamping Voltage Working Voltage (Max) Typical Capacitance 1 KHz (pF) Min Order Qty Standard Package Status Package Type RoHS Stock Check
MLV3220HV240V0500 MLV HV Series High Voltage 3220 390 200VDC 380 500 500 Active Tape & Reel Y Check
MLV3220HV270V0500 MLV HV Series High Voltage 3220 450 225VDC 340 500 500 Active Tape & Reel Y Check
MLV3220HV390V0500 MLV HV Series High Voltage 3220 647 330VDC 125 500 500 Active Tape & Reel Y Check
MLV3220HV430V0450 MLV HV Series High Voltage 3220 705 369VDC 120 500 500 Active Tape & Reel Y Check
MLV3220HV470V0400 MLV HV Series High Voltage 3220 775 385VDC 115 500 500 Active Tape & Reel Y Check
